| Specification | Detail |
|---|---|
| Control Valve Air Flow Capacity | Up to 75 CFM (2,124 L/min) |
| Power Circuit | 11V to 36V |
| Operating Temperature | -40°F to 125°F (-40°C to 52°C) |
| Control System Interface | RS485 Serial (CAN Bus Capable) |
| Data Logger Interface | RS232 Serial or USB |
| Pressure Control Accuracy | ± 2 psi of Actual Tire Pressure |
| System Weight (Single Axle) | 100 lbs (45 kg) |
| System Weight (Tandem Axle) | 145 lbs (65 kg) |
| Tire Group Control | 1 to 4 Separate Groups |
| Inflation Time | 6 to 8 Minutes (Full Re-inflation) |
| Connectivity | Wi-Fi Capable (Data Transfer & Program Updates) |
| Service Life | 10+ Years |
