LIGHT DUTY CARRIER SPECIFICATIONS
| Model | Deck Capacity | Deck Width | Deck Length | Wheel Lift Capacity | Tow Capacity | Winch Capacity | Minimum GVWR |
|---|---|---|---|---|---|---|---|
| 6 Ton XLP | 12,000 lbs. | 96 / 102 in. | 20 / 21 / 22 ft. | 3,500 lbs. | 10,000 lbs. | 10,000 / 12,000 lbs. | 15,000 - 19,500 lbs. |
MEDIUM DUTY CARRIER SPECIFICATIONS
| Model | Deck Capacity | Deck Width | Deck Length | Wheel Lift Capacity | Tow Capacity | Winch Capacity | Minimum GVWR |
|---|---|---|---|---|---|---|---|
| 8.5 Ton XLP | 17,000 lbs. | 96 / 102 in. | 22 - 30 ft. | 3,500 / 5,000 lbs. | 10,000 / 12,000 lbs. | 8,000 / 10,000 / 12,000 lbs. | 25,500 - 33,000 lbs. |
HEAVY DUTY CARRIER SPECIFICATIONS
| Model | Deck Capacity | Deck Width | Deck Length | Wheel Lift Capacity | Tow Capacity | Winch Capacity | Minimum GVWR |
|---|---|---|---|---|---|---|---|
| 10 Ton Steel | 20,000 lbs. | 96 / 102 in. | 24 - 30 ft. | 3,000 / 5,000 lbs. | 7,500 / 12,000 lbs. | 12,000 / 20,000 lbs. | 33,000 lbs. |
| 15 Ton Steel | 30,000 lbs. | 96 / 102 in. | 24 - 30 ft. | 3,000 / 5,000 lbs. | 7,500 / 12,000 lbs. | 20,000 lbs. | 46,000 lbs. |
